Detection
Automated search on the ground and video registration of multicopters’ operators.

Capabilities:
detection and direction finding of signals of multicopters control panels;
detection of operator’s location of multicopter via direction finding of control panel signals from different points;
automated flight by bearing to multicopter’s operator, photo and video registration of operator.

Methods of employment
After multicopter being detected the take-off of the controlled flying platform is carried out to the altitude up to 50-100 m, search and direction finding of signal of the control panel of multicopter.
Search of operator can be performed in two ways:

1. Detection of operator’s location by elevation method

Flying platform carries out direction finding of the control panel from different points. To the crossing point of two bearings (operator’s location) the assault team is sent.

2. Search of operator by bearing

Flying platform carries out automated flight with fluctuating maneuvers and constant direction finding of the panel, visual search, video registration of operator’s actions.

Tactical characteristics:
Frequency range of detection and direction finding of signal 900-6000 MHz
Direction finding accuracy not worse than 5˚
Flight duration up to 30 minutes
Flight distance up tp 2 km
Detection distance of the control panels up to 2 km
Preparation time for take-off not more than 3 min
Video record format up to 1080p60
Dimensions of flying platform:
- in transportation position 600х700х600 mm
- in flight 1140х1140х600 мм
Flight weight 10 kg
